Q Are you a factory or a trading company?

A

We are factory with foreign trade department.
Q When your company was founded?

A

Our company was founded in 2014.
Q Do you have any certificates?

A

We have passed IS09001 and IS014000.
Q What are the maintenance skills of embossing roller？

A

It is necessary to clean the embossing roller to protect the pattern, such as removing rust by acid pickling and removing oil stains by organic matter. And you can use sand blasting treatment to increase surface roughness of the embossing roller, it can improve the binding force between the surface pattern and the embossing roller. Finally, the embossing roller should be kept dry to prevent rusting again.

Share to:

5 Tons Cantilevered Decoiling Machine (Loading hydraulic trolley is optional)

Automatic cutting machine; automatic conveying, automatic palletizing; artificial trolley.

Aluminuml sheet

-5 Tons Cantilevered Decoiling Machine (Loading hydraulic trolley is optional)

-Automatic cutting machine; automatic conveying, automatic palletizing; artificial trolley.

Technical Specification

Embossing Roller Size	ф350-450mmx1000-1600mm width
Embossing Roller Pattern	Convex hull, corn grain, pearl pattern, round ball pattern etc. (can be customized)
Pressed plate	≤0.8mm thick x 1500mm width (Aluminuml sheet)
Embossing Roller Material	Alloy steel solid forging.
Embossing Mode	Upper and lower concave-convex rollers opposing pressure.
Pressure Adjustment	Turbine worm reducer pressurize
Transmission Mode	Gear transmission
Voltage and Power	380V/50HZ, 3P; 11KW (speed 0-40m/min.)
